SCiE2/STiE2 Pro
This is an enhanced BLE location beacon on basis of SCiE2 or STiE2 because it uses 4 x 2700mAh (10800mAh/3.6V) Li-SOCl2 batteries and is integrated with an NFC functionality, besides, it also enlarges its antenna area to enhance the signal transmission range.
Key Features
8-10 years lifespan
NFC
IP67 dust & water resistance
150-200m signal range
BLE5.0
iBeacon
Eddystone
Details
Technical Specifications
Package Details
Key Use Cases
Technical Specifications
- Dimension: 72*72*23(mm), N.W.: 155g
- Chipset: nRF52832/52810
- Battery type: 4*Li-SOCl2 batteries(4*2700mAh,3.6V), replaceable
- Battery life: 8-10 years
- Transmission range: 150-200m in open field
- Protection level: IP67, IK08
- Sensor: NFC, temperature.
- Technical support: BLE5.0 SDKs, App tool, communication protocols, PCB & firmware customizable
Package Details
| Package Details | Inner Box | Carton |
|---|---|---|
| Quantity Packed | 14 pcs | 112 pcs |
| Net Weight | 2.5 Kg | 20 Kg |
| Gross Weight | 2.65 Kg | 20.7 Kg |
| Dimension | 31.5*13*7 cm | 35*32*40 cm |
Key Use Cases
Because of excellent signal transmission range and battery lifespan, it can be the seamless solutions for the following diverse scenarios:
- Shopping habit analysis & precise marketing
- Medical consultation tracking & safety responding
- Information pushing & indoor navigation
Get a quotation
If you don’t mind telling us more details of your PoC or projects, Contact us to get a quotation.
