SCiR1 Road Stud Beacon
SCiR1 is a rugged BLE5.0 beacon developed for parking guidance, parking route navigation and Geo-fencing system. It is integrated with nRF52 BLE5.0 chip and a large-capacity battery to ensure 100m transmission range and 8-10 years lifespan. A tough build in-side-out withstands strict requirements of high pressure and rigged protection, which makes it an ideal hardware solution for maintenance-free outdoor parking scenarios such as hospitals, parks, chemical plants and shared electric vehicles, etc.
Key Features
Explosion-proof
Load pressure 6 tons
Vehicle pressure test
8-10 years battery life
IP68 dust & water resistance
80-100m signal range
Details
Technical Specifications
Package Details
Key Use Cases
Technical Specifications
- Dimension: 110*100*25(mm), N.W.: 155g
- Chipset: nRF52832/52810
- Battery type: Lithium battery 4000mAh
- Battery life: 8-10 years, replaceable
- Transmission range: 100m in open field
- Protection level: IP67, IK08 (Load pressure of 6 tons resistance)
- Technical support: BLE5.0 SDKs, App tool, communication protocols, PCB & firmware customizable
Package Details
| Package Details | Inner Box | Carton |
|---|---|---|
| Quantity Packed | – | – |
| Net Weight | – | – |
| Gross Weight | – | – |
| Dimension | – | – |
Key Use Cases
You can get benefits from the rugged road stud BLE5.0 beacon SCiR1’s use cases, as follow:
Vehicle Management
- Parking & checking in
- Vehicle info collection
- Vehicle positioning & tracking
- Shared vehicle management
Route Navigation
- Navigation plan & optimization
- Access management
- Optional route selection
Parking Space Management
- Parking space usage detection
- Space utilization optimization
- Parking lot or destination positioning
Get a quotation
If you don’t mind telling us more details of your PoC or projects, Contact us to get a quotation.
